Full automatically SAT system with parabolic reflector Ø76 cm, TWIN-LNB (2 receiver to be operated independently from each other) and CAP converter. Installed GPS receiver = quick alignment. The special highlight is the WLAN adapter UFZ131which is available optionally. It enables a WLAN Hotspot which transmits the TV and radio programs direct to the mobile end devices, like tablet or smartphone. The CAP 950 package consists of: turning unit, parabolic reflector with TWIN-LB, mounting plate, mounting material with roof duct. Cable set with 8 m length (2 x coaxial cable and power supply cable). CAP converter (without receiver), external operation panel (optionally). The CAP 950 is prepared for CAP control (WLAN adapter UFZ131 necessary). Configuration and operation by Kathrein App CAP control. Equipment: Turning unit completely with control electronic, parabolic reflector Ø76 cm, GPS receiver. TWIN LNB to connect a 2.receiver. (Controlling to be made via the CAP converter). Full automatically polarization adjustment (SKEW) of the LNB for reception optimization. Very easy servicing due to the cable joint at the turning unit. Aerodynamically set up of only 23 cm height ( in lowered condition). Weight turning unit and antenna: 18,9 kg. Total weight: 32 kg. Max. allowed speed limit : 130 km/h. Technical Data: LNB: V/H (14/18V), low/high (0/22kHz) 2 exits switchable, LNB supply voltage vert. 11,5-14V, hor. 16-19V, Entrance frequency 10,70-12,75 GHz, Exit frequency 950-1950 / 1100-2150 MHz, Oscillator frequency (L.O.) 9,75/10,60 GHz, Figure of merit (G/T) 16,9 / 17,9 GHz dB/K 13,4/13,7, supply voltage (car battery) 10,9 - 13,8V, charging rate from the 12-V-main power supply: start-up current 10 - 12 A, for the satellite searching 3 A, for the TV reception 1,2 A, at stand-by 24 mA, from the receiver 200 mA.
