The electric Carbest lifting bed with a black frame is characterized by its high-quality workmanship and intuitive assembly. It is infinitely height-adjustable. The extra light weight (approx. 35 kg) is achieved through stable aluminum profiles. The static load capacity is 400 kg. The operating speed is 33 mm/second, with a consumption of only 7 A, input 12 V. The maximum stroke (run) is 900 mm.

The product is maintenance-free. Includes slatted caps for the slatted frame for optimal reduction of noise during the journey.

Lifting mechanism:

Lifting height: 850 mm (from bottom edge of bed to bottom edge of bed)

Bed frame height: 85 mm

Bed height: 80 mm

Total height: 165 mm

Distances:

Traveller to trolley (or rail to rail): 1540 mm

Rail to bed frame: 70 mm per side

Rail distance (distance between the center of the two rails): 1438 mm

Bed frame:

Length of bed frame: 1147 mm (without attachment points on the rail)

Width of bed frame: 1680 mm

Other specifications:

• Total mattress dimensions (LxWxH): 1640 x 1107 x 85 mm
